SSOUNDS DSP 4×8
| Specification | SSOUNDS DSP 4×8 SS-DSP-48 |
|---|---|
| Image |  |
| Brand | SSOUNDS |
| Type | Digital loudspeaker processor, 4 in / 8 out |
| Engine | 300 MHz high-performance floating-point DSP · 32-bit |
| Sample rate | 96 kHz |
| Parametric EQ | 5 sections per output · +15 dB to −30 dB in 0.1 dB steps |
| EQ centre frequency | 20 Hz – 20 kHz · 1/36-octave (368 positions) · Q 0.01–10 |
| High-pass filter | 1 per output · 10 Hz – 16 kHz · 1/36-octave steps |
| Low-pass filter | 1 per output · 60 Hz – 22 kHz · 1/36-octave steps |
| Filter types | Bessel / Butterworth 12 · 18 · 24 dB per octave · Linkwitz-Riley 24 dB per octave |
| Limiters | Per output channel |
| Inputs | 4 × XLR3 electronically balanced · CMRR > 65 dB (50 Hz – 10 kHz) |
| Outputs | 8 × XLR3 electronically balanced · max +20 dBu into 600 Ω |
| Control | Front panel · USB (loudspeaker control software) |
| Dimensions (H × W × D) | 44 × 483 × 285 mm |
| Format | 19″ 1U rack |
| Net weight | 4.2 kg / 9 lb |
| Frequency response | 20 Hz – 20 kHz (96 kHz sampling) |
| Certifications | TÜV |
